INDUCTIVE PROXIMITY

INDUCTIVE PROXIMITY Specification

Wireless
No

Operating Temperature
-25C to +70C

Signal Type
Digital

Interface
Cable

Sensitivity
Adjustable

Power Consumption
<10mA

Features
Short-circuit protection, LED indicator

Mounting Type
Flush Mount (Embeddable)

Cable Length
2 meters

Measurement Range
2mm Sensing Distance

Sensor Type
Inductive

IP Rating
IP67

Response Time
<2ms

Application
Detection of metal objects, conveyor systems, packaging machines

Product Type
Inductive Proximity Sensor

Material
Metal Housing, Plastic Components

Input
10-30V DC

Output
NPN Normally Open (NO)

Function
Non-contact object detection

Usage
Industrial automation, position sensing

Accuracy
High precision, repeatable within 0.01mm

Resolution
0.01mm

Voltage
10-30V DC

Weight
Approx. 50g

Frequency
500Hz

Output Indicator
Red LED

Maximum Load Current
200mA

Switching Frequency
500Hz

Protection Circuitry
Reverse polarity and overload protection

Hysteresis
<10% of sensing distance

Housing Diameter
M12

Body Color
Metallic Silver

Standards Compliance
CE, RoHS

About INDUCTIVE PROXIMITY

Experience a celebrated deal with our Noteworthy Inductive Proximity sensor, highly recommended for industrial automation and position sensing. Commanding precise, non-contact object detection, it features a metallic silver metal housing (M12 diameter), IP67 protection, reverse polarity and overload protection for robust reliability. Savings are maximized by its high switching frequency (500Hz), adjustable sensitivity, and efficient power consumption (<10mA). The intuitive red LED output indicator and CE, RoHS compliance ensure trusted performance. This sensor excellently detects metal objects, offering 2mm sensing range and repeatability within 0.01mm-ideal for conveyor systems and packaging machines across demanding environments.

Versatile Applications and Methods for Every Industry

The Inductive Proximity Sensor finds remarkable utility in both general and specific applications, such as metal detection on conveyor systems and position feedback in packaging machines. It serves a variety of roles in automated assembly lines, robotics, and machine tools-making it adaptable for a wide range of industries. With its precise flush mounting capability and embeddable design, setup is straightforward, ensuring consistent detection in factory settings as well as bespoke automation projects.

Payment Terms and Export Market Value

Our Inductive Proximity Sensor has a commanding market value among domestic and international clients. Flexible payment terms are available, including advance payments and letter of credit for secure transactions. We offer prompt delivery, with options for express drop-off or courier services. Samples can be provided as per our transparent sample policy, enabling clients to evaluate the sensor's quality before bulk purchase. Major export destinations include Europe, Middle East, and Southeast Asia.

FAQ's of INDUCTIVE PROXIMITY:

Q: How does the Inductive Proximity Sensor function in industrial automation?

A: The sensor detects metal objects without physical contact using electromagnetic fields, relaying digital signals for position or object presence, ideal for conveyors and automated machinery.

Q: What are the main benefits of using this sensor?

A: Key benefits include high precision, fast response time, robust protection features (IP67), short-circuit safety, and minimal power consumption, ensuring reliable, long-term operation.

Q: Where can this sensor be installed?

A: This sensor is suitable for flush mounting on machinery, conveyor lines, and packaging equipment, or any location where non-contact metal detection is required in industrial environments.

Q: What is the recommended process for application setup?

A: Simply connect the cable interface to a 10-30V DC power supply, adjust the sensitivity as needed, ensure correct mounting, and use the red LED indicator for output verification.

Q: How is the detection accuracy ensured?

A: Accuracy is maintained by the sensor's excellent repeatability within 0.01mm and adjustable sensitivity, ensuring reliable performance in demanding industrial operations.

Q: When should maintenance or checks be performed?

A: Regular inspection is recommended during scheduled maintenance intervals to ensure wiring integrity and proper function of the LED output indicator.
