MARK SENSORS

MARK SENSORS Specification

Features
LED Indicator, Easy Alignment, Compact Design

Response Time
< 0.2 ms

Mounting Type
Panel or Bracket Mounting

Cable Length
2 meters (Standard)

Power Consumption
< 1 W

Wireless
No

Operating Temperature
-10C to +55C

Interface
3-wire, 4-pin Connector

Application
Mark detection on roll-to-roll processing

Measurement Range
Standard 8 mm (varies by model)

Sensitivity
Adjustable via Potentiometer

Signal Type
Digital Output

IP Rating
IP65

Sensor Type
Photoelectric Mark Sensor

Product Type
Mark Sensor

Material
ABS Plastic Housing

Input
10-30 V DC

Output
NPN or PNP (selectable), Relay Output

Function
Detects color marks on packaging materials

Usage
Packaging, Printing, and Textile Industries

Accuracy
High Precision; typically 0.2 mm

Resolution
0.1 mm

Voltage
10-30 V DC

Weight
Approx. 60 g

Adjustment
Manual Sensitivity and Delay Adjustment

Maximum Switching Frequency
5 kHz

Reference Marks Detectable
Black, Blue, Red, Green (on light or dark backgrounds)

Relative Illumination Distance
5 to 15 mm

Housing Color
Black and Grey

Environmental Protection
Dustproof, Moisture Resistant

Shock Resistance
10G (10-55 Hz, Double Amplitude 1.5mm)

Light Source
Red/Green LED (selectable by model)

Connection Type
Pre-wired/Connector Type

Status Display
LED Status Indicator

Storage Temperature
-20C to +70C

Control Method
Automatic and Manual Switching

Operating Humidity
35% to 85% RH (non-condensing)

About MARK SENSORS

Experience the excellent performance of our Mark Sensors, designed to deliver the best accuracy for packaging, printing, and textile industries. With selectable Red/Green LED light sources and commanding reliability, these sensors offer high precision (typically 0.2 mm) and fast response (<0.2 ms). The dustproof, moisture-resistant housing ensures durability, making them excellent for demanding environments. Enjoy superb adaptability with both automatic and manual controls. This limited-time bargain is ending soon - seize the ephemeral opportunity to integrate the best mark detection technology into your workflow.

Versatile Use for Industrial Surfaces

Our Mark Sensors are expertly engineered for a range of uses, including mark detection on roll-to-roll processing lines in packaging, printing, and textile industries. Designed to work effortlessly on multiple surface types-such as black, blue, red, or green marks on light or dark backgrounds-these sensors ensure excellent, reliable results. Whether mounted on panels or brackets, their compact and robust ABS plastic housing enables efficient installation across diverse industrial applications.

Certified, Secure, and Ready for Export

MARK SENSORS come with recognized certifications for safe and reliable operation. We serve the main domestic market in India and actively export to various international markets, ensuring secure shipping and careful packing for every order. Our transparent sample policy and prompt after-sales support offer both buyers and traders the confidence they need. Take advantage of our special offers to experience world-class quality and service, whether as a manufacturer, supplier, or service provider.

FAQ's of MARK SENSORS:

Q: How do I install and align the Mark Sensor on industrial machinery?

A: Mount the Mark Sensor using the panel or bracket mounting options. The device features a compact design and an LED indicator to facilitate easy alignment with the target mark. Refer to the instruction manual for optimal positioning and wiring guidelines.

Q: What types of marks and surfaces can the Mark Sensor detect?

A: The sensor is capable of detecting black, blue, red, and green marks on both light and dark backgrounds. It is ideal for applications involving packaging, printing, and textiles, where high accuracy and varied surface detection are critical.

Q: When should I use the manual versus automatic control methods?

A: Use the automatic control for general applications seeking high-speed and consistent mark detection. Switch to manual controls when adjustments or fine-tuning are necessary, such as when dealing with unusual packaging materials or specific mark colors.

Q: Where can these sensors be used for optimal performance?

A: These sensors are best utilized in industrial settings requiring accurate mark detection on moving materials-such as in roll-to-roll processing lines within packaging plants, printing industries, and textile manufacturing.

Q: What benefits come from the selectable Red/Green LED light sources?

A: Selectable Red/Green LEDs enhance the sensor's adaptability, allowing users to choose the optimal light source for maximum contrast and precision based on the color of the mark and background.

Q: How do I adjust sensitivity and delay on this sensor?

A: The Mark Sensor includes manual potentiometer adjustments for sensitivity and delay, letting users fine-tune detection parameters quickly to achieve high accuracy and consistent performance.
